Automatio pallet changer increases labour productivity, enables workpiece clamping, releasing and gauging on the pallet outside the machine's working space which parts are being machined on the order pallet. The pallet changers are not only cutting cost in manufacturing but also helping customer to improve and monitor quality. The pallet changer is achieved by the combination of servo motor and hydraulic hirth gear drive. This structure ensures high-speed change and high reliability.
Feature| MODEL | UNIT | VMC-400P | VMC-500P | VMC-600P | VMC-700P | |
|---|---|---|---|---|---|---|
| Table | Table surface (two pcs) | 320 x 400 | 400 x 560 | 400 x 720 | 500 x 700 | |
| Table loading | kgs | 200 | 200 | 250 | 250 | |
| Travel | Travel of X/Y/Z-axis | mm | 400 x 400 x 400 | 600 x 400 x 400 | 750 x 450 x 500 | 700 x 500 x 500 |
| Spindle noes to table | mm | 100 - 500 | 100 - 500 | 120 - 620 | 120 - 620 | |
| Spindle center to column surface | mm | 550 | 550 | 600 | 680 | |
| Spindle & Servo motor | Spindle taper | BT-40 | BT-40 | BT-40 | BT-40 | |
| Spindle speed | rpm | 60-8000 (10000 / 12000) opt |
60-8000 (10000 / 12000) opt |
60 - 8000 (10000 / 12000) opt |
60~8000 (10000 / 12000) opt |
|
| Spindle motor | kw | 5.5/7.5 | 5.5/75 | 7.5/11 | 7.5/11 | |
| X/Y/Z Axis servo motor | kw | 1.5/1.5/2 | 1.5/1.5/2 | 2/2/2 | 2/2/2 | |
| Rapid feed rate of X/Y/Z | m/min | 24/24/24 | 24/24/24 | 24/24/24 | 24/24/24 | |
| Cutting feed rate | m/min | 1 - 10 | 1 - 10 | 1 - 10 | 1 - 10 | |
| ACT | ATC Type | Arm type | Arm type | Arm type | Arm type | |
| Tool capaticy | pcs | 24 | 24 | 24 | 24 | |
| Max.tool weight | kgs | 7 | 7 | 7 | 7 | |
| Max.tool length | mm | 250 | 250 | 250 | 250 | |
| Max.tool diameter | mm | 80 | 80 | 80 | 80 | |
| APC | Reciprocating time/tool change time | sec | 2/1.8 | 2/1.8 | 2/1.8 | 2/1.8 |
| Changing time | sec | 7 | 7 | 7 | 7 | |
| Driven by servo motor | kw | 1.5 | 1.5 | 2 | 2 | |
| Rotary Way | angle | 180 | 180 | 180 | 180 | |
| Miscellaneous | Air pressure | kgs/cm² | 6 | 6 | 6 | 6 |
| Machine weight | kgs | 5000 | 5500 | 6000 | 6800 | |
| Machine size (L x W x H) | mm | 2400 x 2200 x 2550 | 2400 x 2200 x 2550 | 2620 x 2250 x 2770 | 2800 x 2250 x 2770 | |
| Control | FANUC / MITSUBISHI / SIEMENS | |||||
